New 2020 - CNC Milling Machine

New 2020 CNC Milling Machine

TABLE

Size 1500 x 3,000mm

T-Slot (Width x Quantity) 9 x 22mm x 160

Maximum Table Load 10000kg

X-Axis Travel 3,200mm

Y-Axis Travel 1,700mm

Z-Axis Travel 1,000mm

Distance Between Columns 1,800mm

Distance from Table Top to Spindle Nose 250 to 1,250mm

SPINDLE

Spindle Taper BT-50

Spindle Speed 6,000 rpm

Drive Method Gear Box

Spindle Motor 15/18.5 kW

Spindle Torque 490 Nm / 605 Nm

Ram Size 350 x 350mm

FEEDS

Rapid Feed X,Z 15m/min

Rapid Feed Y 20m/min

Cutting Feed Rate X,Y,Z 10m/min

ATC (Option)

Tool Storage Capacity 24 Tools

Magazine Type BT-50

Tool Holder Style Ø35mm

Max. Tool Diameter(Adj.Pots Empty) Ø110mm (Ø 220mm)

Max. Tool Length 300mm

Max. Tool Weight 20kg

OTHER

Power Capacity 40 KVa

Machine Weight 30000Kg

Machine Size (LxWxH) 945x420x510

Control FANUC Oi-MF
